Customized Different Size Ultrasonic Piezoelectric Pzt Piezo Ceramic Plate
We are professional in manufacturing piezoelectric ceramics for more than 50 years. We can make customized products as your requirements. The company now has 150 employees, including 35 professionals in material research and development, sensor research and development, equality of indicators and parameters, and process design.Among them, there are more than 10 postgraduates with intermediate and senior technical titles, and the talent team has strong comprehensive research and development ability.In recent years, the company has obtained two national invention patents and one design patent. In 2016, it was approved as a high-tech enterprise by the state.
PiezoelectricCeramics (PZT) materials are categorized as functional ceramics. In sensors they make it possible toconvert forces, pressures and accelerations into electrical signals, and in sonic and ultrasonic transducers and actuators they convert electric voltages into vibrations or deformations.PiezoelectricCeramics materials are classified according to their chemical composition on the one hand, and by the specific application conditions on the other.
Features ·
High dielectric constant
· Very high Q-factor
· Excellent temperature stability
· Tight tolerance
· Recommended applications: base station DR filters, satellite communication LNB and so on
· Available in different sizes
Application
1. ultrasonic cleaning trasnducer
2. ultrasonic welding tansducer
3. ultrasonic beauty transducer
4. ultrasonic underwater transducer
5. ultrasonic immersible transucer
6. ultrasonic screening transducer
7. ultrasonic cutting transducer
8. ultrasonic atomization transducer
9. ultrasonic emulsifier
Types of Piezoceramics Material Piezoelectric Ceramic
Ring Piezoelectric Ceramic
Disc Piezoelectric Ceramic
Tube Piezoelectric Ceramic
Cylinder Piezoelectric Ceramic Ball/Hemisphere
Piezoelectric Ceramic Square/Rectangular
Piezoelectric Ceramics (PZT) materials are categorized as functional ceramics. In sensors they make it possible toconvert forces,pressures and accelerations into electrical signals, and in sonic and ultrasonic transducers and actuators they convert electric voltages into vibrations or deformations.PiezoelectricCeramics materials are classified according to their chemical composition on the one hand, and by the specific application conditions on the other.
| spec | Dimension
(mm) | Radial frequency
(KHz) | Capacitance
(pf) | Dielectric dissipation factor
tanδ(%) | Electromechanical coupling coefficient
(Kr) | Impedance
Zr(Ω) | Thickness frequency
(KHz)) | Mechanical
quality factor
(Qm) |
| PLS-YHJP-25103 | Φ25×Φ10×3 | 66.4 | 1240±12.5% | ≤0.3 | ≥0.46 | ≤15 | 683±5% | 800 |
| PLS-YHJP-25104 | Φ25×Φ10×4 | 66.4 | 930±12.5% | ≤0.3 | ≥0.46 | ≤15 | 512±5% | 800 |
| PLS-YHJP-40125 | Φ40×Φ12×5 | 45.9 | 2070±12.5% | ≤0.3 | ≥0.46 | ≤15 | 410±5% | 800 |
| PLS-YHJP-40155 | Φ40×Φ15×5 | 42.2 | 1960±12.5% | ≤0.3 | ≥0.46 | ≤15 | 323±5% | 500 |
| PLS-YHJP-40205 | Φ40×Φ20×5 | 37.9 | 1700±12.5% | ≤0.3 | ≥0.47 | ≤15 | 410±5% | 800 |
| PLS-YHJP-50206 | Φ50×Φ20×6 | 33.2 | 2490±12.5% | ≤0.3 | ≥0.46 | ≤15 | 341±5% | 500 |
| PLS-YHJP-501765 | Φ50×Φ17×6.5 | 34.8 | 2430±12.5% | ≤0.3 | ≥0.46 | ≤15 | 315±5% | 800 |
| PLS-YHJP-50236 | Φ50×Φ23×6 | 31.2 | 2340±12.5% | ≤0.3 | ≥0.47 | ≤15 | 341±5% | 800 |
| PLS-YHJP-50276 | Φ50×Φ27×6 | 29.3 | 2100±12.5% | ≤0.3 | ≥0.47 | ≤15 | 341±5% | 800 |
| PLS-YHJP-603010 | Φ60×Φ30×10 | 31.25.3 | 1922±12.5% | ≤0.3 | ≥0.47 | ≤18 | 205±5% | 800 |
| FOR MORE OEM SIZE WELCOME TO ENQUIRE SALERS |
Q: Do you have it in stock?
A: Most of product available, if you have special requirement, pls feel free contact us, all issue can be solved through communication.
Q: Could you advise to us the design based on our special requirements or based on our object samples?
A: Of course, Our mission is make your idea show in the products itself.
Q: How long do you make the order product?
A: Our main mark is fast shipment, usually 3-7days after all details confirmed.
Q: . Do you have operating manual?
A: Of course, we will put it with the goods together. Also we will upload video in youtube and inform you the related link.
Q: How about the quality?
A: We have export to many other customers from all over the world,the feed back is good,quality is the first for our factory, our main markets is USA and European etc
Q: Could you do OEM?
A: Yes, of course.Everybody like OEM,We cherish the OEM VIP buyer like you,We can produce according customers’ requirement,just send us your requirements and design of drawing and sample
Q: Could we as your agent?
A: Of course.We are looking for sole agent in some Country who have the willing to cooperate with us for long business term.
Q: Terms of Payment
A: We have flexible and active payment if order huge.
Q: What custom requirements can you accept?
A: LOGO, product appearance, tool head size, packaging requirements, special customized requirements will be accepted, etc.
